Brightlink BL-VT Pro LED Display Vacuum Tool - Effortless Front Maintenance for LED Video Walls
$249.00 USD
Features
- 190” Diagonal Screen (13.8’ x 7.8’)
- .9mm Small Pitch HD LED Cabinets
- VX600 All-in-One LED Wall Controller
- Slim mount Cabinets 60mm ( 2.36”)
- Integrated Box for easy connection
- 16:9 Standard Video Aspect Ratio
- Super Bright 500cd/m2
- 3840Hz Refresh rate
- View Distance from 6’-165’
- 11,289,600 PIXELS (ABOVE 4K RESOLUTION )
- Seamless / line free Interlocking cabinets
- Front repairable modules with included Vacuum tool
INSTALLATION CABINET VIEW
INSTALLATION FRONT VIEW WITH MODULES
Hardware Features
- Industry-standard input connectors:
- 2x 3G-SDI
- 1x HDMI 2.0
- 4x SL-DVI
- 16 Ethernet output ports load up to 10,400,000 pixels.
- 3 independent layers
- 1x 4K×2K main layer 2x 2K×1K PIPs (PIP 1 and PIP 2)
- Adjustable layer priorities
Specification
| Pixel pitch | 9mm |
| Module Resolution | W320xH180 Pixels |
| Module Size | 300mm x 168.75mm |
| Led Packing | 1010 |
| Scanning Method | 45s |
| LED composition | 1R 1G 1B |
| Cabinet Size | 600 x 337.5 x 60mm / 23.62” x 13.3” x 2.36” |
| Module QTY | w2 x h2 = 4pcs |
| Physical Resolution | w640 x h 360 Pixels |
| Power Consumption (MAX) | 120w |
| Power Consumption (AVG) | 40W |
| Cabinet Material | Die-Cast Aluminum |
| Net Weight | 5.5KG / 12LBS |
| Screen Area | 13.8’ x 7.8’ x 190” Diagonally |
| Whole Screen Resolution | = 11,289,600 PIXELS |
| Cabinet Quantity | 7 pcs wide x 7 pcs high = 49pcs total |
| Brightness | 600cd/m2 |
| Colors | 281 Trillion |
| Brightness Control | Software 256 level adjustable |
| Grey Level | 16 |
| View Distance | 2m-50m / 6’ - 165’ |
| Refresh Rate | 3840Hz |
| Drive Mode | 1/43s |
| Life Span | 100,000h |
| MTBF | 1000h |
| Control Mode | Synchronous control or Asynchronous control |
| Frame Frequency | 60Hz |
| Certifications | CE/ROHS/FCC/CCC/ISO9001 |
| Operation Temperature | -20C - +45 C |
| Operation Humidity | 10% - 95% |
