Brightlink BL-VT Pro LED Display Vacuum Tool - Effortless Front Maintenance for LED Video Walls
$249.00 USD
Features
- 108” Diagonal Screen (7.87’ x 4.43’)
- 1.25mm Small Pitch HD LED Cabinets
- VX600 All-in-One LED Wall Controller
- Slim mount Cabinets 60mm ( 2.36”)
- Integrated Box for easy connection
- 16:9 Standard Video Aspect Ratio
- Super Bright 500cd/m2
- 3840Hz Refresh rate
- View Distance from 6’-165’
- 2,073,600 Pixels (FULL HD 1080P)
- Seamless / line free Interlocking cabinets
- Front repairable modules with included Vacuum tool
Product Brochure
Product Application
Further Features
- V-Can Support;
- Genlock;
- Supports up to 3x layers;
- Memory for 10 presets;
- Cascading via USB possible;
- Display configuration without computer possible;
- Control via USB or LAN;
Specifications
| Pixel pitch | 1.25mm |
| Module Resolution | W240xH135 Pixels |
| Module Size | 300mm x 168.75mm |
| Led Packing | 1010 |
| Scanning Method | 45s |
| LED composition | 1R 1G 1B |
| Cabinet Size | 600 x 337.5 x 60mm / 23.62” x 13.3” x 2.36” |
| Module QTY | w2 x h2 = 4pcs |
| Physical Resolution | w480 x h 270 Pixels |
| Power Consumption (MAX) | 120w |
| Power Consumption (AVG) | 40W |
| Cabinet Material | Die-Cast Aluminum |
| Net Weight | 5.5KG / 12LBS |
| Screen Area | 2.4m(W) x 1.35m(H) /7.87’ x 4.43’ x 108” Diagonally 3.24sqm / 35 sqft |
| Whole Screen Resolution | 1920(W) x 1080(H) = 2,073,600 Pixels |
| Cabinet Quantity | 4pcs wide x 4 pcs high = 16pcs total |
| Brightness | 500cd/m2 |
| Colors | 281 Trillion |
| Brightness Control | Software 256 level adjustable |
| Grey Level | 16 |
| View Distance | 2m-50m / 6’ - 165’ |
| Refresh Rate | 3840Hz |
| Drive Mode | 1/43s |
| Life Span | 100,000h |
| MTBF | 1000h |
| Control Mode | Synchronous control or Asynchronous control |
| Frame Frequency | 60Hz |
| Certifications | CE/ROHS/FCC/CCC/ISO9001 |
| Operation Temperature | -20C - +45 C |
| Operation Humidity | 10% - 95% |
| Supply voltage | AC 100-240V, 50/60HZ |
| Dimensions | 483.6 x 351.2 x 50.1mm (WxDxH) |
| Power consumption | 28 watts |
| Weight | 4kg |
Hardware Features
| 2x HDMI 1.3 (HDMI-In & Loop) (max. 1920×1200@60Hz), Custom EDID's possible | |
| 1x DVI (1920×1200@60Hz, Custom EDID's possible | |
| 1x 3G-SDI (max. 1920×1080@60Hz) |
| 6x LED-Out (RJ45) | |
| 1x HDMI 1.3 Out (fixed resolution of 1920×1080@60Hz when the output is used as monitoring) | |
| 2x OPT-Out (10G) |
