Specification: |
General: |
Model: H Series H2 |
Form Factor: 2U rackmount |
Pixel Capacity: |
Up to 41.6 million pixels |
Up to 26 million pixels (standard configuration) |
Maximum Resolution: |
Single Video Connector: |
Max width: 2,560 pixels |
Max height: 2,560 pixels |
Single Ethernet Port: |
Max width: 10,752 pixels |
Max height: 10,752 pixels |
Single OPT (Optical) Port: |
Max width: 16,384 pixels |
Max height: 16,384 pixels |
Layering: |
Layers Per Card: Up to 16 layers per card |
Preset Playlists: |
Preset Playback Support: Up to 2000 playlists |
Control Interfaces: |
TCP/IP |
RS232 |
Input Card Options: |
H_4xDVI Input Card: 4 DVI inputs |
H_4xHDMI Input Card: 4 HDMI inputs |
H_2xHDMI2.0 + 2xDP1.2 Input Card: 2 HDMI 2.0 + 2 DisplayPort 1.2 inputs |
H_1xHDMI2.0 + 1xDP1.2 Input Card: 1 HDMI 2.0 + 1 DisplayPort 1.2 input |
H_1xHDMI2.0 Input Card: 1 HDMI 2.0 input |
H_1xDP1.2 Input Card: 1 DisplayPort 1.2 input |
H_2xHDMI2.0 Input Card: 2 HDMI 2.0 inputs |
H_2xRJ45 IP Input Card: 2 RJ45 IP video inputs |
H_4x3G SDI Input Card: 4 3G SDI inputs |
H_1x12G SDI Input Card: 1 12G SDI input |
H_2xCVBS + 2xVGA Input Card: 2 composite video inputs + 2 VGA inputs |
H_2xDP1.1 Input Card: 2 DisplayPort 1.1 inputs |
H_4xVGA Input Card: 4 VGA inputs |
H_2xAudio Input + 2xAudio Output Card: Audio input/output card |
H_4xHDBaseT Input Card: 4 HDBaseT inputs |
H_STD I/O Card: Standard input/output card |
Output Card Options: |
H_4xDVI Output Card: 4 DVI outputs |
H_4xHDMI Output Card: 4 HDMI outputs |
H_1xHDMI2.0 Output Card: 1 HDMI 2.0 output |
H_16xRJ45 + 2xFiber Sending Card: 16 RJ45 + 2 fiber outputs |
H_4xFiber Sending Card: 4 fiber outputs |
H_20xRJ45 Sending Card: 20 RJ45 outputs |
H_4x3G SDI Output Card: 4 3G SDI outputs |
H_4xHDBaseT Output Card: 4 HDBaseT outputs |
H_2xRJ45 + 1xHDMI1.3 Preview Card: 2 RJ45 outputs + 1 HDMI 1.3 preview |
