Brightlink's New 8x8 8K 48Gbps HDMI 2.1 HDMI Matrix with, CEC, ARC Function, HDR and Dolby Digital Plus

Save 5%

Price:
Sale price$1,797.00 Regular price$1,897.00
5% Off
SKU: BL-8X8-8K-CEC
Shipping Time: Standard 8-12 business day
Stock:
In stock
SKU: BL-8X8-8K-CEC
Searching for a trusted installer in your area to assist with your project?
Find an Installer

Frequently Bought Together

Brightlink’s New Long Range 8K 90m 40Gbps HDBaseT / HDMI Extender can extend high definition video / audio signal, RS-232, bi-directional IR, at distances up to 90m/295ft between Transmitter (TX) and Receiver (RX) via a single CAT5e/6 cable.

Brightlink’s New Long Range 8K 90m 40Gbps HDBaseT / HDMI Extender can extend high definition video / audio signal, RS-232, bi-directional IR, at distances up to 90m/295ft between Transmitter (TX) and Receiver (RX) via a single CAT5e/6 cable.

$797.00 USD

Features

  • HDMI 2.1 and HDCP 2.3 compliant
  • 8 × HDMI inputs can be independently routed to 8 × HDMI outputs
  • Video resolution is up to 8K60Hz 4:2:0, 8K30Hz 4:4:4 and 4K120Hz 4:4:4
  • Support 48Gbps video bandwidth
  • HDR, HDR10, HDR10+, Dolby Vision pass-through
  • Support 8K->4K or 8K/4K->1080p downscaling for each output port
  • VRR, ALLM, QMS, QFT, SBTM are supported
  • Support optical audio and balanced analog audio output
  • Advanced EDID management
  • Control via front panel buttons, IR remote, RS-232, and Web GUI

Package Contents:

  • 1 × 48Gbps 8K 8×8 HDMI Matrix
  • 1 × 24V/3.75A Locking Power Adapter
  • 1 × IR Remote
  • 1 × IR Wideband Receiver Cable (12V, 1.5m)
  • 1 × AC Power Cord (1.5m)
  • 1 × RS-232 Serial Cable (1.5m, male to female head)
  • 8 × 5pin-3.81mm Phoenix Connector
  • 8 × Machine Screw (KM3*6)
  • 2 × Mounting Ear
  • 1 × User Manual

Technical

HDMI Compliance HDMI 2.1
HDCP Compliance HDCP 2.3
Video Bandwidth 48Gbps
Video Resolution Up to 8K60Hz 4:2:0, 8K30Hz 4:4:4 and 4K120Hz 4:4:4
Color Space RGB_4:4:4, YCbCr_4:4:4, YCbCr_4:2:2, YCbCr_4:2:0
Color Depth 8/10/12-bit
HDR Formats HDR, HDR10, HDR10+, Dolby Vision, HLG
Audio Formats
HDMI IN/OUT:
LPCM, Dolby Digital/Plus/EX, Dolby True HD, Dolby Atmos, DTS,
DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
AUDIO BREAKOUT:
Optical Outputs: LPCM 2.0CH/Dolby/DTS 5.1CH
Balanced Analog Audio Outputs: LPCM 2CH
ESD Protection Human body model — ±8kV (Air-gap discharge) & ±4kV (Contact discharge)

Connection

Input ports 8 × HDMI INPUT [Type A, 19-pin female]
Output ports:
8 × HDMI OUTPUT [Type A, 19-pin female]
8 × OPTICAL AUDIO OUT [S/PDIF]
8 × AUDIO OUT [3.5mm Stereo Mini-jack]
Control ports:
1 × TCP/IP [RJ45]
1 × RS-232 [D-Sub 9]
1 × IR EXT [3.5mm, Stereo Mini-jack]

Mechanical

Housing: Metal Enclosure
Color: Black
Dimensions: 440mm [W] × 203mm [D] × 44.5mm [H]
Weight: 2.94kg
Power Supply: Input: AC 100-240V 50/60Hz, Output: DC 24V/3.75A
(US/EU standard, CE/FCC/UL certified)
Power Consumption: 70W (Max)
Operating Temperature: 32 - 104°F / 0 - 40°C
Storage Temperature: -4 - 140°F / -20 - 60°C
Relative Humidity: 20 - 90% RH (no-condensing)
